Specifications

Model
ND-RT-16XXM Series
(XX lfting height between 6-10.5 mtrs)
ND-RT-20XXM Series
(XX lifting height between 6-12.5 mtrs)
Characteristics
Manufacturer
MiMA
MiMA
Power type
Battery
Battery
Operation type
Seated
Seated
Operation mode
Electric proportional control
Electric proportional control
Rated capacity
Q(kg)
1600
2000
Load center
C(mm)
600600
Load distance, centre of drive axle to forkx(mm)
371407
Front overhang
x1(mm)
184205
Wheelbase
y(mm)
14001500
Weight
Service weight(incl. battery)
kg
37004131
Axle load, fork backward, unladen drive side/load side
kg
2309 / 13912446 / 1510
Axle load, fork forward,laden drive side/load side
kg
799 / 4501730 / 5226
Axle load, fork backward,laden drive side/load side
kg
2042 / 32582169 / 3761
Wheel
Wheel type, drive side/load side
Solid PU/Solid PU
Solid PU/Solid PU
Load wheel size
mm
φ300×120φ343×120
Drive wheel size
mm
φ343×120
φ343×120
Number of wheels, front/rear(x=drive wheel)
2/ 1X

2/ 1X
Wheel tread, load side
b11(mm)
1170
1170
Size
Fork tilt, front/rear
α/β(°)
2/4
2/4
Mast closed height
h1(mm)
As per mast spec
As per mast spec
Free Lift height
h2(mm)
As per mast spec
As per mast spec
Lift height
h3(mm)
As per mast spec
As per mast spec
Mast extended height with load-backrest
h4(mm)
As per mast spec
As per mast spec
Overhead guard height
h6(mm)
2200
2200
Seat height
h7(mm)
1122
1122
Side shift distance
±50
±50
Support leg height
h8(mm)
320
363
Overall length
l1(mm)
2354
2409
Length to face of forks
l2(mm)
1275
1339
Overall width
b1/b2(mm)
1270/1290
1270/1290
Fork size
l/e/s(mm)
1070×100×35
1070×122×40
Fork carriage width
b3(mm)
1020
1020
Fork outside width
b5(mm)
232-728
254-750
Inner leg width
b4(mm)
906
906
Reach distance
l4(mm)
555
613
Mast ground clearance
m1(mm)
75
75
Aisle width for pallet 1000*1200mm(C=500mm)
Ast(mm)
2716
2791
Aisle width for pallet 800*1200mm(C=600mm)
Ast(mm)
2767
2835
Turning radius
Wa(mm)
1647
1747
Overall length(without forklift)
l7(mm)
1796
1918
Function
Driving speed(laden/unladen)
km/h
14/14
14/14
Lifting speed(laden/unladen)
mm/s
330/500
330/500
Lowering speed(laden/unladen)
mm/s
530/520
530/520
Mast movement speed, forward/backward
mm/s
200200
Max. gradeability (laden/unladen)
%(tanθ )
1010
Braking method
Hydraumatic
Hydraumatic
Drive
Driving motor power (S2-60min)
kw
8.0
8.0
Lifting motor power (S3-15%)
kw
12.812.8
Steering motor power(S2-60min)
kw
0.4
0.4
Lead acid battery, voltage/capacity
V/Ah
48/420
48/560
Options: Lithium battery voltage/capacity
V/Ah
48/300
48/460[6]
Battery weight
kg
715
920
Battery replacement method
Front pull
Front pull
Sound level at driver's ear
dB(A)
7575

Features

  • Advanced Curtis controller, more stable and safer.

  • Maintenance-free AC drive system makes the vehicle react more quickly and accurately, And Counterbalance Forklift Truck is equipped with a full AC system.

  • Pure electric steering and small steering force makes the operator comfortable and energy saving.

  • Multi-way valve controls the lifting and lowering of the fork, and the control precision is high.

  • Standard turning speed limit and high lifting speed limit.

  • Standard maximum lifting height limit.

Mast Specifications

"Triplex full free mast - ND-RT-16XXM Series
(XX lfting height between 6-10.5 mtrs)"
Model
MFZ16
16T-60
16T-70
16T-8016T-9016T-10016T-105
Lift height
h3(mm)
6000
7000
800090001000010500
Mast extended height with load-backrest
h4(mm)7235
8235
9235
102351123511735
Mast closed height
h1(mm)
2720
3153
3486
392042534420
Free lift height(incl.load-backrest)
h2(mm)
1445
1878
2211
264529783145
Free lift height(incl.load-backrest)
h2(mm)
1576
2008
2340
287632083376
"Triplex full free mast - ND-RT-20XXM Series
(XX lifting height between 6-12.5 mtrs)"
Model
MFZ16
20T-60
20T-70
20T-8020T-9020T-10020T-105 20T-125
Lift height
h3(mm)
6000
7000
8000900010000105001250
Mast extended height with load-backrest
h4(mm)
7235
8235
9235
10235112351173513735
Mast closed height
h1(mm)
2720
3153
3486
3920425344205086
Free lift height(incl.load-backrest)
h2(mm)
1445
1878
2211
2645297831453811
Free lift height(incl.load-backrest)
h2(mm)
1576
2008
2340
2876320833764040
