Description

Nido automatic box strapping machines are low cost, easy to operate and have low energy consumption. Easy maintenance, no greasing and mechanism is stable and durable.

TECHNICAL SPECIFICATIONS

Model ND-EOLP-ST-APA013
Arch Sizemm1. Standard Size: W 800mm X H 600mm (inner size)
(it’s possible to customize arch size)
2. Material: Aluminium alloy
Power SupplyV/Hz3 phase 415V 50/60HZ 1.27kW, 10A
Strapping Force0 to 90 kg (adjustable)
Strap Sealing PositionBottom
Table Heightmm800 mm (it’s possible to customize height)
Strap Cycle Speedmm≤ 2.5
Applicable Strapmm9 to 15 mm, 0.55 to 1 mm thk.
Applicable PP Strap Spool W:160mm
Inner dia.: 200mm to 210mm,
Out dia.:400mm to 500mm
Packing TypeParallel 1 to 2 straps by photoelectric control &
manual operation
DimensionsmmL 1580 × W 620 × H 1420mm
Machine WeightkgN.W: 280kg G.W: 320kg
Noise LeveldB ≤ 75 DB

Electrical Configuration:

  • PLC:Siemens
  • Contactor:Schneider
  • Relay:Schneider
  • Button:TE
  • Motor:MEIWA
  • Sensor switch & proximity switch:P+F
Model ND-EOLP-ST-JN85PRU
Arch Sizemm800W x 600H mm
Power SupplyV440V 50Hz 3Ph
Strap Cycle SpeedSec/cycle2.5 sec/cycle
Tension StrengthkgsMax. 70 Kgs
Strap Widthmm9~15
Dimensionsmm1550W x 800D x 1470H mm
Table Heightmm810mm
Package Sizemm300~820W, 30~560H mm
Machine Weightkg330
Gross Weightkg430
Power Roller Speedm/min15
Sealing MethodHeat Sealing

FEATURES

Nido Automatic Online Box Strapping Machine | ND-EOLP-ST-APA013

  • PLC control, stable performance
  • Hinged working table
  • Fully Automatic unmanned Strapping Machine provided with powered driven rollers.
  • Whole machine is controlled by PLC control
  • It can automatically detect box, automatically apply strap, automatically moves box.
  • It is used in fully automatic production lines.

Nido Automatic Online Box Strapping Machine – Heavy Duty | ND-EOLP-ST-JN85PRU

  • Standardized power roller table model with 2 sets of photocell.
  • Optional straps No. is available for 1, 2 or no strapping on the packages.
  • More straps application is also available as an option before order is fixed.
  • This model can incorporate with input and output conveyors as a strapping system. The control system of conveyors can be connected with this model.
  • An optional photocell to control the table transmitting is available, which can auto-stop the table when no package is input.
  • Equipped with Table Roller Cover.
