- Mainly used for loading and unloading of trucks in logistics/3PL distribution centers, eCommerce fulfillment centers, postal express, food manufacturing, electrical appliances industries and warehouses.
- Hydraulic lifting device can be added to control the height of the conveyor
- Can be operated in forward or reverse direction depending your loading unloading needs.
- Legs can be added in the four sides to adjust the height with the truck or container.
- Various value added options can be added like SKU counter, in-line weighing & dimensioning, in-line bar-code scanning etc.
| Type | Section Number | Fixed length (mm) – A | Extended Length (mm) – B | Total Length (mm) – C | Belt Width (mm) |
|---|---|---|---|---|---|
| ND-C-TBC-3S-5/7-800 | 3 | 5000 | 7000 | 12000 | 600/800 |
| ND-C-TBC-3S-5.4/6.6-800 | 5400 | 6600 | 12000 | 600/800 | |
| ND-C-TBC-3S-6/8.6-800 | 6000 | 8600 | 14600 | 600/800 | |
| ND-C-TBC-3S-4/5-800 | 4000 | 5000 | 9000 | 600/800 | |
| ND-C-TBC-3S-9.5/12-800 | 9500 | 12000 | 21500 | 600/800 | |
| ND-C-TBC-4S-5/10-800 | 4 | 5000 | 10000 | 15000 | 600/800 |
| ND-C-TBC-4S-6/12.6-800 | 6000 | 12600 | 18600 | 600/800 | |
| ND-C-TBC-4S-7/14.6-800 | 7000 | 14600 | 21600 | 600/800 | |
| SQ-XA-4-6/12.6-G | 6000 | 12600 | 18600 | 600/800 | |
| ND-C-TBC-4S-7/14.6-800 | 7000 | 14600 | 21600 | 600/800 | |
| ND-C-TBC-4S-7.5/16-800 | 7500 | 16000 | 23500 | 600/800 | |
| ND-C-TBC-5S-6/16-800 | 5 | 6000 | 16000 | 22000 | 600/800 |
| ND-C-TBC-5S-6/16-800 | 6000 | 16000 | 22000 | 600/800 | |
| ND-C-TBC-5S-7/17.5-800 | 7000 | 17500 | 24500 | 600/800 | |
| ND-C-TBC-5S-7.5/21-800 | 7500 | 21000 | 28500 | 600/800 | |
| ND-C-TBC-5S-10/20-800 | 10000 | 20000 | 30000 | 600/800 |
