Single drum parrot beak attachment

  • Pick up drums automatically; driver never leaves seat while lifting and releasing drums
  • Use with open or closed head drums.
  • Handles steel, fiber and poly drums with 360kg.
  • Completely Mechanical; drum grab requires no hydraulic or electrical connections.
  • Double grip head has different position to fit different height.
  • Rim grip drum handler can come supplied with a rubber cushioned support.
  • Strong ‘parrot beak’ gripping mechanism reducing dangerous and costly spillages and drum damage.
  • Hard steel gripping head for a long service life with low maintenance and operating costs.
  • Detachable frame saves transport cost.

* Note : R denotes for Rubber belt on drum support (to avoid metal to metal contact)

Model ND-D-FA-PB-1ND-D-FA-PB-1BND-D-FA-PB-1R
CapacityKg360*1360*1500*1
Eagle Grip Adjustable Heightmm525-750465-690600-750
Single Fork Sleeve Sizemm150*55150*55150*55
Outer Width of Double Fork Sleevemm660660750
Fork Sleeve Lengthmm600600-
External Dimension (L*W*H)mm780*670*850780*670*850910*760*850
Net WeightKg414552

Double drum parrot beak attachment

  • Pick up drums automatically; driver never leaves seat while lifting and releasing drums
  • Use with open or closed head drums;
  • Handles steel, fiber and poly drums with 2 drum options with 720 kg (360kg x 2)
  • Completely Mechanical drum grab requires no hydraulic or electrical connections;
  • Double grip head has different position to fit different height;
  • Rim grip drum handler can come supplied with a rubber cushioned support;
  • Strong ‘parrot beak’ gripping mechanism reducing dangerous and costly spillages and drum damage;
  • Hard steel gripping head for a long service life with low maintenance and operating costs
  • Detachable frame saves transport cost;

* Note : R denotes for Rubber belt on drum support (to avoid metal to metal contact)

Model ND-D-FA-PB-2ND-D-FA-PB-2BND-D-FA-PB-2R
CapacityKg360*2360*2500*2
Eagle Grip Adjustable Heightmm525-750465-690600-750
Single Fork Sleeve Sizemm150*55150*55
Outer Width of Double Fork Sleevemm750750750
Fork Sleeve Lengthmm755755755
External Dimension (L*W*H)mm910*910*850910*910*850910*760*850
Net WeightKg637563

Four drum parrot beak attachment

  • Pick up drums automatically; driver never leaves seat while lifting and releasing drums.
  • Use with open or closed head drums.
  • Handles steel, fiber and poly drums with 2 drum options with 1440 kg (360 kg x 4).
  • Ideal for transporting and palletizing drums.
  • Use of a special parrot beak structure with automatic adjusting core frame which is speedy and safe.
  • Simply position the center guide over the four drums, lower and lift.
  • It is designed for carrying 4 drums at one time which is fit for operation inside containers.
  • Applicable for use in harbors, large-scale raw material warehouses and other places where drum transporting need to be done in large amount.
  • Suitable for 3-ton forklift capacity.
Model ND-D-FA-PB-4ND-D-FA-PB-4-1
CapacityKg500*4500*4
Eagle Grip Adjustable HeightmmN.A.N.A.
Single Fork Sleeve Sizemm175*65175*65
Outer Width of Double Fork Sleevemm880880
Fork Sleeve Lengthmm960960
External Dimension (L*W*H)mm980*960*500980*960*500
Net WeightKg174174
